Thumbnail index
A visible five-image dock selects full-frame architectural photographs with a precise white selection edge.
Choose a thumbnail. Up, Down, Home and End move the focused selection.
Subframe Original · MIT
Add to your project
Component source
Standalone React component. Styles are included.
React only. No additional packages.
Download images (5)
Save these files in your static assets folder at /motion/assets/, or update their paths in the component.
- Chartres Cathedral, West Facade; Royal Portal, Central Bay · CC0-1.0
- Modern brutalist architecture with geometric shapes · Unsplash
- Brutalist concrete office building · Unsplash
- Montmartre · CC0-1.0
- Rue de la Montagne-Sainte-Geneviève near the Intersection of Rue LaPlace (Rue de la Montagne-Sainte-Geneviève prés de carrefour de la rue LaPlace) · CC0-1.0
Render the default export inside a container with a defined height. Its optional active prop stops movement when false. This example works with React 19; Next.js projects can use it as a client component.
View source code
/**
* MIT License
*
* Copyright (c) 2026 Subframe
*
* Permission is hereby granted, free of charge, to any person obtaining a copy
* of this software and associated documentation files (the "Software"), to deal
* in the Software without restriction, including without limitation the rights
* to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
* copies of the Software, and to permit persons to whom the Software is
* furnished to do so, subject to the following conditions:
*
* The above copyright notice and this permission notice shall be included in all
* copies or substantial portions of the Software.
*
* THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
* IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
* FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
* AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
* LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
* OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
* SOFTWARE.
*/
"use client"
import { useEffect, useRef, useState } from "react"
function useCalm(active: boolean) {
const [reduced, setReduced] = useState(true)
useEffect(() => {
const media = matchMedia("(prefers-reduced-motion: reduce)")
const sync = () => setReduced(media.matches)
sync()
media.addEventListener("change", sync)
return () => media.removeEventListener("change", sync)
}, [])
return reduced || !active
}
const archive = [
["/motion/assets/concrete-geometries.webp", "GEOMETRY"],
["/motion/assets/cathedral-columns.webp", "RHYTHM"],
["/motion/assets/paris-street.webp", "PASSAGE"],
["/motion/assets/concrete-projections.webp", "MASS"],
["/motion/assets/montmartre.webp", "CONTOUR"],
]
export default function ThumbnailIndex({ active = true }: { active?: boolean }) {
const calm = useCalm(active)
const [current, setCurrent] = useState(0)
const [instant, setInstant] = useState(false)
const buttons = useRef<(HTMLButtonElement | null)[]>([])
const choose = (n: number, immediate = false) => {
if (!active) return
setInstant(immediate)
setCurrent(Math.max(0, Math.min(archive.length - 1, n)))
}
return (
<section className="sf-thumbnail-index" data-calm={calm || instant} aria-label="Architecture thumbnail index">
<style>{`.sf-thumbnail-index{width:100%;height:100%;min-height:280px;background:#242820;color:#fff;position:relative;overflow:hidden;font-family:Arial,sans-serif;container-type:size}.sf-thumbnail-index *{box-sizing:border-box}.sf-thumbnail-index .ti-image{position:absolute;inset:0;width:100%;height:100%;object-fit:cover;transition:opacity 260ms ease,transform 420ms cubic-bezier(.22,1,.36,1)}.sf-thumbnail-index:after{content:'';position:absolute;inset:0;background:linear-gradient(0deg,#0007,transparent 52%);pointer-events:none}.sf-thumbnail-index .ti-label{position:absolute;z-index:2;bottom:26px;left:28px;right:130px}.sf-thumbnail-index .ti-label strong{display:block;font-size:41px;letter-spacing:-.055em;line-height:1;font-weight:500}.sf-thumbnail-index .ti-rail{position:absolute;z-index:3;right:20px;top:50%;transform:translateY(-50%);width:83px;padding:7px;display:grid;gap:5px;background:#141714e8;box-shadow:0 0 0 1px #ffffff1f,0 6px 24px #0004;border-radius:7px}.sf-thumbnail-index .ti-rail button{position:relative;display:block;width:69px;height:49px;border:0;padding:2px;background:transparent;border-radius:3px;cursor:pointer;transition:background 140ms ease}.sf-thumbnail-index .ti-rail button[aria-current=true]{background:#fff;box-shadow:inset 0 0 0 1px #10181040}.sf-thumbnail-index .ti-rail button:not([aria-current=true]):hover{background:#ffffff45}.sf-thumbnail-index .ti-rail img{display:block;width:100%;height:100%;object-fit:cover;border-radius:1px;filter:brightness(.82)}.sf-thumbnail-index .ti-rail button[aria-current=true] img{filter:none}.sf-thumbnail-index .ti-rail span{position:absolute;left:7px;bottom:6px;font:9px/1 Arial,sans-serif;color:#fff;text-shadow:0 1px 3px #000,0 0 5px #000}.sf-thumbnail-index button:focus-visible{outline:2px solid #ffe0a4;outline-offset:3px}.sf-thumbnail-index button:disabled{cursor:default}.sf-thumbnail-index[data-calm=true] .ti-image{transition:none}`}</style>
{archive.map(([image, label], i) => (
<img
className="ti-image"
key={image}
src={image}
alt={current === i ? label : ""}
aria-hidden={current !== i}
style={{ opacity: current === i ? 1 : 0, transform: `scale(${current === i ? 1 : 1.025})` }}
/>
))}
<div className="ti-label">
<strong>{archive[current][1]}</strong>
</div>
<div
className="ti-rail"
role="group"
aria-label="Architecture index"
onKeyDown={(e) => {
if (!["ArrowDown", "ArrowUp", "Home", "End"].includes(e.key) || !active) return
e.preventDefault()
const next =
e.key === "Home"
? 0
: e.key === "End"
? 4
: Math.max(0, Math.min(4, current + (e.key === "ArrowDown" ? 1 : -1)))
choose(next, true)
buttons.current[next]?.focus()
}}
>
{archive.map(([image, label], i) => (
<button
key={image}
ref={(el) => {
buttons.current[i] = el
}}
type="button"
aria-label={`View ${label.toLowerCase()}`}
aria-current={current === i}
disabled={!active}
tabIndex={current === i ? 0 : -1}
onClick={(e) => choose(i, e.detail === 0)}
>
<img src={image} alt="" />
<span aria-hidden="true">{String(i + 1).padStart(2, "0")}</span>
</button>
))}
</div>
</section>
)
}
Where it works well
Browse a short visual sequence while seeing every available image and the current selection.
Reduced motion
Images switch immediately for reduced motion and keyboard selection; host pause disables the thumbnail buttons.
Things to know
The five-image collection intentionally fits without internal scrolling. Longer collections need an explicit scroll or paging strategy. Image rights are separate from the original code.
