Specimen fan
Botanical plates fan around one brass binding, bringing the selected specimen upright for inspection.

Drag or select a specimen. Use the arrows, Left, Right, Home and End to browse.
Subframe Original · MIT
Add to your project
Component source
Standalone React component. Styles are included.
React only. No additional packages.
Download images (4)
Save these files in your static assets folder at /motion/assets/, or update their paths in the component.
Render the default export inside a container with a defined height. Its optional active prop stops movement when false. This example works with React 19; Next.js projects can use it as a client component.
View source code
/**
* MIT License
*
* Copyright (c) 2026 Subframe
*
* Permission is hereby granted, free of charge, to any person obtaining a copy
* of this software and associated documentation files (the "Software"), to deal
* in the Software without restriction, including without limitation the rights
* to use, copy, modify, merge, publish, distribute, sublicense, and/or sell
* copies of the Software, and to permit persons to whom the Software is
* furnished to do so, subject to the following conditions:
*
* The above copyright notice and this permission notice shall be included in all
* copies or substantial portions of the Software.
*
* THE SOFTWARE IS PROVIDED "AS IS", WITHOUT WARRANTY OF ANY KIND, EXPRESS OR
* IMPLIED, INCLUDING BUT NOT LIMITED TO THE WARRANTIES OF MERCHANTABILITY,
* FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. IN NO EVENT SHALL THE
* AUTHORS OR COPYRIGHT HOLDERS BE LIABLE FOR ANY CLAIM, DAMAGES OR OTHER
* LIABILITY, WHETHER IN AN ACTION OF CONTRACT, TORT OR OTHERWISE, ARISING FROM,
* OUT OF OR IN CONNECTION WITH THE SOFTWARE OR THE USE OR OTHER DEALINGS IN THE
* SOFTWARE.
*/
"use client"
import { useEffect, useRef, useState } from "react"
const specimens = [
["/motion/assets/botanical-cabbage-rose.webp", "Cabbage rose"],
["/motion/assets/botanical-iris.webp", "Gold-banded iris"],
["/motion/assets/botanical-turban-lily.webp", "Turban lily"],
["/motion/assets/botanical-crocus.webp", "Crocus"],
]
const clamp = (n: number) => Math.max(0, Math.min(specimens.length - 1, n))
export default function RopeGallery({ active = true }: { active?: boolean }) {
const root = useRef<HTMLElement>(null),
position = useRef(1),
target = useRef(1),
velocity = useRef(0),
raf = useRef(0)
const draw = useRef(() => {}),
run = useRef(() => {})
const drag = useRef<{ x: number; start: number } | null>(null),
moved = useRef(false)
const [selected, setSelected] = useState(1),
[reduced, setReduced] = useState(true)
useEffect(() => {
const media = matchMedia("(prefers-reduced-motion: reduce)")
const sync = () => setReduced(media.matches)
sync()
media.addEventListener("change", sync)
return () => media.removeEventListener("change", sync)
}, [])
useEffect(() => {
const el = root.current
if (!el) return
const cards = Array.from(el.querySelectorAll<HTMLElement>(".sf-plate"))
let last = 0
const paint = () => {
const width = Math.min(152, el.clientWidth * 0.27),
height = Math.min(244, el.clientHeight - 112)
const spread = Math.min(27, ((el.clientWidth - width) / height) * 14)
cards.forEach((card, i) => {
const distance = i - position.current
card.style.width = `${width}px`
card.style.height = `${height}px`
card.style.transform = `translateX(-50%) rotate(${distance * spread}deg)`
card.style.zIndex = String(i === Math.round(position.current) ? 30 : 20 - Math.ceil(Math.abs(distance) * 4))
})
}
const tick = (time: number) => {
raf.current = 0
const dt = Math.min((time - (last || time - 16)) / 1000, 0.032)
last = time
velocity.current += ((target.current - position.current) * 210 - velocity.current * 26) * dt
position.current += velocity.current * dt
paint()
if (Math.abs(target.current - position.current) > 0.001 || Math.abs(velocity.current) > 0.005)
raf.current = requestAnimationFrame(tick)
else {
position.current = target.current
velocity.current = 0
paint()
}
}
const start = () => {
cancelAnimationFrame(raf.current)
last = 0
if (reduced) {
position.current = target.current
velocity.current = 0
paint()
} else if (active && !document.hidden) raf.current = requestAnimationFrame(tick)
}
draw.current = paint
run.current = start
const ro = new ResizeObserver(paint)
ro.observe(el)
paint()
const visibility = () => (document.hidden ? cancelAnimationFrame(raf.current) : start())
document.addEventListener("visibilitychange", visibility)
if (active) start()
return () => {
cancelAnimationFrame(raf.current)
ro.disconnect()
document.removeEventListener("visibilitychange", visibility)
}
}, [active, reduced])
const choose = (value: number, instant = false) => {
target.current = clamp(value)
setSelected(Math.round(target.current))
if (instant || reduced) {
cancelAnimationFrame(raf.current)
position.current = target.current
velocity.current = 0
draw.current()
} else run.current()
}
return (
<section
ref={root}
className="sf-rope-gallery"
aria-label="Botanical specimen fan"
onKeyDown={(event) => {
const next =
event.key === "ArrowRight"
? target.current + 1
: event.key === "ArrowLeft"
? target.current - 1
: event.key === "Home"
? 0
: event.key === "End"
? 3
: null
if (next === null) return
event.preventDefault()
choose(next, true)
root.current?.querySelectorAll<HTMLButtonElement>(".sf-plate")[Math.round(clamp(next))]?.focus()
}}
>
<style>{`.sf-rope-gallery{position:relative;width:100%;height:100%;min-height:280px;overflow:hidden;background:radial-gradient(ellipse at 50% 25%,#34584d,#183b32 85%);color:#e9eadc;font-family:Arial,sans-serif;isolation:isolate}.sf-rope-gallery *{box-sizing:border-box}.sf-rope-gallery:before{content:'';position:absolute;inset:0;opacity:.12;pointer-events:none;background-image:repeating-linear-gradient(0deg,transparent 0 2px,#d5e5d20c 2px 3px)}.sf-rope-gallery .sf-plate{position:absolute;left:50%;bottom:82px;transform-origin:50% calc(100% - 17px);border:0;border-radius:4px 4px 11px 11px;padding:8px 8px 37px;background:#eae8dc;color:#28382c;box-shadow:0 1px 0 #fffffff0 inset,0 -1px 0 #6c68557a inset,1px 3px 3px #09170e30,4px 9px 16px #08221950;cursor:grab;touch-action:pan-y;user-select:none}.sf-rope-gallery .sf-plate:active{cursor:grabbing}.sf-rope-gallery .sf-plate:before{content:'';position:absolute;inset:0;border-radius:inherit;pointer-events:none;background:linear-gradient(115deg,#fff5,transparent 40%,#6d665211);z-index:1}.sf-rope-gallery .sf-plate img{width:100%;height:100%;display:block;object-fit:contain;mix-blend-mode:multiply;pointer-events:none}.sf-rope-gallery .sf-plate span{position:absolute;bottom:30px;left:0;width:100%;font:italic 14px Georgia,serif;text-align:center}.sf-rope-gallery .sf-plate:focus-visible{outline:2px solid #f2cf74;outline-offset:4px}.sf-rope-gallery .sf-pivot{position:absolute;z-index:40;left:50%;bottom:90px;transform:translateX(-50%);height:18px;width:18px;border:1px solid #a88847;border-radius:50%;background:conic-gradient(from 30deg,#d5ba77,#8b6c32,#ead597,#ae8d4b,#e6ce91,#8b6c32,#d5ba77);box-shadow:0 1px 1px #fff9 inset,0 2px 2px #16251bcc,0 0 0 3px #574a261f;pointer-events:none}.sf-rope-gallery .sf-pivot:after{content:'';position:absolute;inset:4px;border:1px solid #705d38;border-radius:50%;box-shadow:0 1px 1px #fff8}.sf-rope-gallery footer{position:absolute;left:24px;right:24px;bottom:10px;display:flex;height:44px;align-items:center;justify-content:space-between;font-size:11px}.sf-rope-gallery .sf-count{font-variant-numeric:tabular-nums;font-size:10px}.sf-rope-gallery .sf-pagination{display:flex;align-items:center;gap:8px;font-variant-numeric:tabular-nums;font-size:10px}.sf-rope-gallery footer button{width:44px;height:44px;border:0;color:inherit;background:transparent;cursor:pointer;font:21px Arial;border-radius:50%;transition:background-color 150ms,transform 150ms}.sf-rope-gallery footer button:disabled{opacity:.3;cursor:default}.sf-rope-gallery footer button:active{transform:scale(.96)}.sf-rope-gallery footer button:focus-visible{outline:2px solid #f2cf74}@media(hover:hover){.sf-rope-gallery footer button:hover:not(:disabled){background:#ffffff10}}`}</style>
{specimens.map(([image, title], index) => (
<button
key={image}
className="sf-plate"
tabIndex={selected === index ? 0 : -1}
aria-label={`View ${title}`}
aria-pressed={selected === index}
onPointerDown={(event) => {
if (event.button !== 0) return
cancelAnimationFrame(raf.current)
velocity.current = 0
moved.current = false
drag.current = { x: event.clientX, start: position.current }
event.currentTarget.setPointerCapture(event.pointerId)
}}
onPointerMove={(event) => {
if (!drag.current || !root.current) return
const dx =
((event.clientX - drag.current.x) * root.current.clientWidth) / root.current.getBoundingClientRect().width
if (Math.abs(dx) > 4) moved.current = true
if (!moved.current) return
position.current = clamp(drag.current.start - dx / 95)
draw.current()
setSelected(Math.round(position.current))
}}
onPointerUp={(event) => {
if (!drag.current) return
drag.current = null
if (event.currentTarget.hasPointerCapture(event.pointerId))
event.currentTarget.releasePointerCapture(event.pointerId)
if (moved.current) choose(Math.round(position.current))
}}
onPointerCancel={() => {
drag.current = null
choose(Math.round(position.current))
}}
onLostPointerCapture={() => {
if (!drag.current) return
drag.current = null
choose(Math.round(position.current))
}}
onClick={(event) => {
if (!moved.current || event.detail === 0) choose(index, event.detail === 0)
}}
>
<img src={image} alt="" draggable={false} />
<span>{title}</span>
</button>
))}
<span className="sf-pivot" aria-hidden="true" />
<footer>
<span className="sf-count" aria-live="polite">
{String(selected + 1).padStart(2, "0")} / 04
</span>
<div className="sf-pagination">
<button
aria-label="Previous specimen"
disabled={selected === 0}
onClick={(event) => choose(target.current - 1, event.detail === 0)}
>
←
</button>
<button
aria-label="Next specimen"
disabled={selected === 3}
onClick={(event) => choose(target.current + 1, event.detail === 0)}
>
→
</button>
</div>
</footer>
</section>
)
}
Where it works well
Give a small visual collection a tactile, direct-manipulation browsing surface.
Reduced motion
Selection changes are immediate; direct dragging remains available. Host pause freezes spring interpolation.
Things to know
Four bounded specimen plates with a shared pivot; the cards stay bound and do not detach or open a lightbox.
